IBM Blade Server Monitoring

Blade Servers with a modular structure allow several physical servers to be housed in the same chassis, thus reducing the use of space and energy in data centers. HPE, IBM and Cisco are among the leading companies in the production of this equipment. Moein has the ability to monitor the blade servers of these companies using the standard interface. The monitored performance indicators of IBM blade servers are presented as follows.

Ibm Blade.‌overview.en

Chassis General Information:

  1. Model
  2. Uptime
  3. Contact Info
  4. Host Name
  5. Location
  6. Machine Type
  7. Machine Model
  8. Serial Number
  9. UUID
  10. Manufacture
  11. Hardware Revision
  12. FRU Number
  13. Manufacture Date
  14. Part Number
  15. FRU Serial Number
  16. Manufacture ID
  17. Product ID
  18. Chassis Type
  19. Chassis Name
  20. Number of Supported Fan Packs
  21. Number of Supported Processor Blades
  22. Number of Supported SW Module
  23. Number of Supported MM
  24. Number of Supported PM
  25. Number of Supported MT
  26. Number of Supported Blowers
  27. Installed Blades
  28. Installed SW Module
  29. Installed MM
  30. Installed PM
  31. Installed MT
  32. Installed Blowers
  33. Active MM
  34. KVM Owner
  35. Media Tray Owner
  36. Installed Power Fans
  37. Chassis Model Type
  38. Chassis Model SubType
  39. System Time
  40. Time Zone

Ibm Blade.‌details.en

Chassis Health:

  1. Management Module Temperature
  2. Front Panel Temperature
  3. Front Panel 2 Temperature
  4. + 5 Volt
  5. + 3.3 Volt
  6. + 12 Volt
  7. - 5 Volt
  8. + 2.5 Volt
  9. + 1.8 Volt
  10. System Health Summary
  11. Total Health
  12. Front Pannel Error LED
  13. Front Pannel Information LED
  14. Front Pannel Temperature LED
  15. Front Pannel Identity LED
  16. Total Available DC Power
  17. Total AC Power
  18. Thermal Output

Ibm Blade.‌kpi.en

Blades General information :

  1. Bay Number
  2. Vendor
  3. FRU Number
  4. Hardware Revision
  5. Serial Number
  6. Machine Type
  7. Part Number
  8. FRU Serial
  9. Machine Model
  10. Blade Daughter Card Type
  11. Blade Daughter Manufacturing Id
  12. Blade Daughter FRU Number
  13. Blade Daughter Hardware Revision
  14. Blade Daughter Serial Number
  15. Blade Daughter Part Number
  16. Blade Daughter FRU Serial
  17. Blade Media Tray
  18. KVM Blade

Blades Expansion Card General information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Serial Number
  6. Machine Type
  7. Part Number
  8. FRU Serial
  9. Machine Model

 Blades KVM General information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Serial Number
  6. Machine Type
  7. Part Number
  8. FRU Serial
  9. Machine Model

 WWN development card General Information:

  1. Bay Number
  2. Name
  3. Type
  4. WWN/GUID 1
  5. WWN/GUID 2
  6. WWN/GUID 3
  7. WWN/GUID 4

Blades firmware information:

BIOS information:

  1. Bay Number
  2. Blade Exists
  3. Blade Power State
  4. Blade Name
  5. Blade Firmware Build ID
  6. BIOS Revision
  7. BIOS Firmware Date
  8. Level Status

Diags Information:

  1. Bay Number
  2. Blade Exists
  3. Blade Power State
  4. Blade Name
  5. Blade Firmware Build ID
  6. Diag Revision
  7. Diag Firmware Date
  8. Level Status

Ibm Blade.‌blade.overview.en

Blades Management Module Information:

  1. Bay Number
  2. Blade Exists
  3. Blade Power State
  4. Blade Name
  5. System Management Processor Build ID
  6. System Management Processor Revision
  7. Level Status
  8. Network Management Auto Discovery
  9. Network Management Status
  10. Blade Management Ip Address
  11. Blade Management Mac Address
  12. Blade Management Switch ID

Blades KVM middleware information:

  1. Bay Number
  2. Blade Exists
  3. Blade Power State
  4. Blade Name
  5. KVM Revision

Blade KPIs:

  1. Blade ID
  2. Blade Exists
  3. Blade Power State
  4. Blade Health State
  5. Blade Name
  6. Blade System Error LED
  7. Blade Information LED
  8. Blade KVM LED
  9. Blade Media Tray LED
  10. Blade Identity LED
  11. Configured Maximum Power
  12. Average Power
  13. CPU Clock Rate
  14. Maximum CPU Clock Rate
  15. Blade Remote Power Control
  16. Blade Remote Media Tray
  17. Blade KVM Control
  18. Blade Wake On LAN Enablement
  19. Blade Remote Media Tray Switch Enablement
  20. Connection Type
  21. KVM Owner
  22. MT Owner
  23. Include Expansion Board
  24. Support Capacity On Demand
  25. Include Expansion Board 2
  26. Blade KVM Status
  27. Connection Type
  28. High Speed Connection
  29. I/O Compatibility Status
  30. CPU 1 Temp
  31. CPU 2 Temp
  32. CPU 3 Temp
  33. CPU 4 Temp
  34. Temp Capability
  35. Sensor Temp
  36. +5 Voltage
  37. +3.3 Voltage
  38. +12 Voltage
  39. +2.5 Voltage
  40. +1.5 Voltage
  41. +1.25 Voltage
  42. IPMI Capability
  43. Sensor Voltage
  44. RAM Total Status
  45. Drive Total Status

Ibm Blade.‌blades.en

Boot order of blades:

  1. Blade ID
  2. Blade Exists
  3. Blade Power State
  4. Blade Health State
  5. Blade Name
  6. Boot Sequence

Switch Modules:

Hardware Information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Part Number
  6. FRU Serial
  7. SW WWN/GUID/SASID
  8. SW WWN/GUID/SAS Type

Firmware information:

  1. Bay Number
  2. SW Exists
  3. SW Type
  4. Build ID
  5. Build Date
  6. Revision Number

KPIs:

  1. Bay Number
  2. SW Exists
  3. SW Power State
  4. SW IP Address
  5. SW Mask
  6. SW Gateway
  7. SW IP Config Method

Ibm Blade.‌switches.en

Powers:

Hardware Information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Part Number
  6. FRU Serial

Controller Information:

  1. Fan Pack Controller ID
  2. Fan Pack Exists
  3. Controller Revision

KPIs:

  1. Module Exists
  2. Module State

Ibm Blade.‌power.view.en

Power Domain KPIs:

  1. Power Domain Number
  2. Power Domain Status
  3. Power Domain First Module
  4. Power Domain Second Module
  5. Power Domain Policy
  6. Power Domain Total Power
  7. Power Domain Allocated Power
  8. Power Domain Remaining Power
  9. Power In Used

Power Domain 1 KPIs:

  1. Bay Number
  2. Blade Server Primary Slot
  3. Power Domain 1 Throttle Status
  4. Module Name
  5. Module State
  6. Current Power
  7. Max Power
  8. Min Power
  9. CPU Duty Cycle
  10. Module Throttle
  11. Power Capability
  12. Measured/Static

Power Domain 2 KPIs:

  1. Bay Number
  2. Blade Server Primary Slot
  3. Power Domain 2 Throttle Status
  4. Module Name
  5. Module State
  6. Current Power
  7. Max Power
  8. Min Power
  9. CPU Duty Cycle
  10. Module Throttle
  11. Power Capability
  12. Measured/Static

Power Fans KPIs:

  1. Fan Pack Exists
  2. Fan Pack State
  3. Fan Pack Count
  4. Fan Pack Average Speed Percentage
  5. Fan Pack Average Speed
  6. Fan Pack Controller State
  7. Fan Pack Error LED

Ibm Blade.‌powers.en

Blowers

Hardware information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Part Number
  6. FRU Serial

Firmware information:

  1. Bay Number
  2. Blower Exists
  3. Revision Number

KPIs:

  1. Blower Speed
  2. Blower State
  3. Blower RPM
  4. Blower Controller State
  5. Blower Error LED

Ibm Blade.‌blower.view.en

Management Modules

Hardware information:

  1. Bay Number
  2. Manufacturing ID
  3. FRU Number
  4. Hardware Revision
  5. Part Number
  6. FRU Serial
  7. Management Module Presence
  8. Management Module External IP
  9. Is Primary?
  10. Management Module Health

Firmware information:

  1. Firmware Name
  2. Build ID
  3. Revision Number
  4. Hardware Revision
  5. File Name
  6. Build Date

Ibm Blade.‌managment.view.en

Multimedia Tray:

Hardware information:

  1. Manufacturing ID
  2. FRU Number
  3. Hardware Revision
  4. Part Number
  5. FRU Serial

Communication Protocols:

  • SNMP V1, V2, V3
